GIS Data Collector U17A

Short Description:

Applications The U17A industrial handheld integrated a dedicated GNSS receiving board, a combination of connectivity options and standard features, including BD9 series port, LRBT, NFC, Wi-Fi and 4G, provides entire solutions for high-accuracy GIS applications. The fully-rugged IP rate is designed for field use. The U17A industrial handheld come ready for you with applications possibilities in power companies, agriculture and geological industries, forestry, field services and GIS/surveying. ...

Send email to us Send email to us Download as PDF

Product Detail

Product Tags

Applications

The U17A industrial handheld integrated a dedicated GNSS receiving board, a combination of connectivity options and standard features, including BD9 series port, LRBT, NFC, Wi-Fi and 4G, provides entire solutions for high-accuracy GIS applications. The fully-rugged IP rate is designed for field use. The U17A industrial handheld come ready for you with applications possibilities in power companies, agriculture and geological industries, forestry, field services and GIS/surveying.

Specifications

Model	U17A
Over View
Processor	1.3GHZ
ROM	2GB
RAM	16GB
Operation system	Android
Multi-language	Yes
Keypad	27 numeric + programmable keys
Mic	Yes
Speaker	3,7’’ sunlight readable with integrated touch screen
Display resolution	480 x 640
Camera	8megapixel
Dimension	200mm x 96mm x 32mm
Weight	515g with battery
GNSS Performance
GPS L1	Yes
BDS B1	Yes
GLonass L1	Yes
Channels	72 channels
NMEA-0183	Yes
External antenna	Yes
Accuracy (Internal Accord accuracy)
Aulonomous	2.5m
SBAS	2m
Time to first fix
Hot start	1s
Warm start	29s
Cold start	29s
Re-acquisition	1s
Communications and data storage
Bluetooth	V4.0
Long range Bluetooth	Optional
NFC	Optional
Datalink	4G（full netcom）
WIFI	Yes
USB port	Type B USB
Serial port	BD9
Voice	Yes
Storge extension	TF card, up to 32GB
Power
DC input	DC 5V, 1A
Detachable Li-ion battery	6500mA, 3.7V
Environment specifications
Operationg temperature	-20℃ ~ +60℃
Storage temperature	-30℃ ~ +70℃
Sand, dust & water	IP67
Drop	1.2m protection
